Product Details:
Payment & Shipping Terms:
|
| Processing Type: | Plastic Thermoforming Machine | Condition: | New |
|---|---|---|---|
| Product Type: | Plastic Lid | Voltage: | 380V 50HZ(220V 60HZ) |
| Power(W): | 22KW | Dimension(L*W*H): | 5000*1600*2100mm |
| Weight: | 4000KG | Warranty: | One Year |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Max. Cutting Speed: | 10-35 Times/min |
| Max. Forming Length: | 260mm | Max. Forming Width: | 470mm |
| Max. Forming Depth: | 70mm | Available Material: | PP/PS/PET/PVC/PLA |
| Material Thickness: | 0.1mm-1.5mm | Heating Power: | 16KW |
| Motor Power: | 6KW | Pressure Of Water Supply: | 0.2MPa |
| Exhaust Volume: | >=0.6m3/min | ||
| High Light: | thermoforming cup making machine,plastic plate making machine |
||
Brief Introduction:
HLD-470 series automatic thermoforming machine,as the first domestic new-type machine,is researched and developed by our scientific researcher according to the market demands and our past production technology.
This machine is a multi station automatic machine, which solve the problems of food packaging hygienc standards. It not only solves a lot of problems effectively in the production of PP, PS, PET, PVC and PLA
plastic products, such as large capital investment, large labor input, complicated production process, lower hygienic security, etc, but also has extensive usage.
It can be used in the production of PP, PS, PET, PVC, PLA plastic products using in metals, food, pharmaceutical, etc. The machine enjoys beautiful appearance and good price. It is popular with the customers at home and abroad!
Technical Parameter:
| Name | HLD-470B |
| Max. Cutting Speed | 10-35 times/min |
| Max. Forming Length | 260mm |
| Max. Forming Width | 470mm |
| Max. Forming Depth | 70mm |
| Available Material | PP/PS/PET/PVC/PLA |
| Material Thickness | 0.1mm-1.5mm |
| Heating Power | 16KW |
| Motor Power | 6KW |
| Power and Total Power | 380V 50HZ(220V 60HZ)22KW Three-phase and four-wire |
| Pressure of Water Supply | 0.2MPa |
| Water Consumption | 0.3m3/h (Tap water or Circulating cooling water) |
| Exhaust Volume | ≥0.6m3/min |
| Air Pressure | 0.6-0.8MPa |
| Machine Install Size | 5000×1600×2100mm |
| Packing Size | 5200×1800×2300mm |
| Max. Width of Material | 510mm |
| Weight | 4000KG |
Packaging&Shipping of carton box making machine prices
Standard export wooden box, within 45 days after the receipt of advanced payment
Q: Why choose us?
1.More than ten years of production experience, let us pay more attention to product detail.
2.Materia selectionl, we insist on using domestic and international famous brands of accessories,
to ensure the stability of the equipment.
3.About after sale service, customer problems in using the machine, our staff will be in the first time
to solve the program are given.
Q:I have never use this kind of packaging machie,how to control?
1.Each machine we are accompanied by the relevant operating instructions.
2.Our engineers can operate through a video demonstration.
3.We can send engineers to the scene teaching.
Q:How to choose a best fit packaging machine?
1.Give us the product size, weight, size of the packaging bag, packaging style, we will make a
detailed plan for your reference.
2.Provide us the packaging products,they will be packed in our machines and mailed to you for
your reference.
Q:What makes us outstanding from peers?
1.A most strict QC standard in the industry is applied.
2.CE and IOS certificate.
3.High productivity with advanced machines.
4.A wide selection of styles, and product types.
