Small Tea Cup Manufacturing Machine , Disposable Cup Machine Easy Operating

Large Image : Small Tea Cup Manufacturing Machine , Disposable Cup Machine Easy Operating

Product Details:

Place of Origin:	Zhejiang, China (Mainland)
Brand Name:	HLD
Certification:	CE
Model Number:	HLD-C12

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set/Sets
Price:	Negotiable

Contact Now

Detailed Product Description

Condition:	New	Product Type:	Paper Cup Machine
Processing Type:	Paper Folding Machine	Voltage:	380V 3 Phases
Power(W):	11KW	Dimension(LWH):	1880mm1450mm1900mm
Weight:	2500kg	Warranty:	1 Year
After-sales Service Provided:	Engineers Available To Service Machinery Overseas	Paper Cup Top Diameter:	Min 45mm To Max 104mm
Paper Cup Bottom Diameter:	Min 35mm To Max 75mm	Paper Cup Height:	Min 35mm~~Max 115mm
Paper Cup Size Range:	2 Ounces To 12 Ounces	Paper Weight Range:	180gsm To 350gsm
Speed:	70 To 80 Pcs/min	Air Comsumption:	0.15 Cbm/min
High Light:	high speed paper cup machine , paper cup production machine

Product Description

Automatic 12 ounces disposable coffee paper cup making machine

Model	HLD-C12
Paper cup size	2-12oz (adjustable mold)
Paper cup top diameter	45-104mm
Paper cup bottom diameter	35-75mm
Paper cup height	35-115mm
Forming paper cup speed	70-80pcs/min
Paper cup Material	180-350gsm
Main motor power	11kw
Power supply	380v/220v
Dimension	1880mm1450mm1900mm

Main Features

1. Paper cup bottom sealing by Leister Hot Air System.
2. Cup side sealing by ultrasonic system.
3. With our unique original designed bottom knurling system, single shaft, Korea type, this ensures the
low leaking ratio and high quality of paper cups.
4. Paper sucking system adopt the vacuum pump, big power and stable running.
5. With unique Open Cam design, the drive system is conducted by the stable gear system,
it would be more stable when machine running at a high speed.
6. With automatic lubricating system, it will automatic lubricating to every moving parts when machine runs.
7. Every cam will be harden to ensure it can run for a long long time.
8. Machine is designed with double turning plate.
9. Equipped with automatic cup collecting stacking and counting system.
10. Bottom paper we have a special pre feeding system, so the bottom paper feeding is “0” waste.
11. Bottom is die cut and feed in to the finished cup body directly, so its more efficient and less
malfunctioning from bottom.

Small Tea Cup Manufacturing Machine , Disposable Cup Machine Easy Operating

Application

The Machine Is Mainly Used to Produce Many Different Kinds Of Plastic Lids , Food Containers, Plastic Bowl, Plates , Toys Package, Food Trays , Hardward Trays, Medicine Trays and Etc.The Sheet Material Can Be HIPS, PVC, PET, PS.Custom Mould Is Welcomed.

Our Service

1 year machine quality warranty
24 hours online technical support, and online presale guide.
Oversea technician service is available, which will ensure you trouble free.
Welcome to contact us whenever you need us.
we are ready to offer you the best quality, best price and best service for you!

RFQ

1. Q: Are you a factory or trading company?

A: We are a factory .
2. Q: How does your factory do regarding quality control?
A: Quality is our Culture , We have passed CE certifate and we have a special QC department in charge of products' quality.
3. Q: How long is the warranty period ?
A: one year warranty .
4. Q: What's the main market of your company?
A: We have exported machines to Canada, Spain, Brazil, Russia, Korea, Vietnam, Philippines, Thailand, Indonesia, U.A.E, Algeria, Syria, Pakistan, Iran, Saudi Arabia, Africa, South America and etc
5. Q: How much production capacity of your company one year?
A: This depends on your needs.
6. Q: Can we see the machine operation in your factory?
A: Yes , We can arrange to run the machines when you come to visit our factory.
7. Q: How to reach our factory?
A: Wenzhou Airport to our factory , about 50mins ; Ruian Train Station to our factory , about 15mins.
8. Q: How about After-sale service?
A: Engineers available to service machinery overseas and training how to install & run the machine.
