Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Product Type: | Paper Cup Machine |
|---|---|---|---|
| Processing Type: | Paper Folding Machine | Voltage: | 380V 3 Phases |
| Power(W): | 11KW | Dimension(L*W*H): | 1880mm*1450mm*1900mm |
| Weight: | 2500kg | Warranty: | 1 Year |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Name: | Paper Cup Making Machine |
| Paper Cup Top Diameter: | Min 45mm To Max 104mm | Paper Cup Bottom Diameter: | Min 35mm To Max 75mm |
| Paper Cup Height: | Min 35mm~~Max 115mm | Paper Cup Size Range: | 2 Ounces To 12 Ounces |
| Paper Weight Range: | 180gsm To 350gsm | Speed: | 70 To 80 Pcs/min |
| Air Comsumption: | 0.15 Cbm/min | Design: | Open Cam |
| System: | Automatic Lubricating | ||
| Highlight: | high speed paper cup machine,paper cup production machine |
||
|
Model
|
HLD-C12
|
|
Paper cup size
|
2-12oz (adjustable mold)
|
|
Paper cup top diameter
|
45-104mm
|
|
Paper cup bottom diameter
|
35-75mm
|
|
Paper cup height
|
35-115mm
|
|
Forming paper cup speed
|
70-80pcs/min
|
|
Paper cup Material
|
180-350gsm
|
|
Main motor power
|
11kw
|
|
Power supply
|
380v/220v
|
|
Dimension
|
1880mm*1450mm*1900mm
|
1. Paper cup bottom sealing by Leister Hot Air System.
2. Cup side sealing by ultrasonic system.
3. With our unique original designed bottom knurling system, single shaft, Korea type, this ensures the
low leaking ratio and high quality of paper cups.
4. Paper sucking system adopt the vacuum pump, big power and stable running.
5. With unique Open Cam design, the drive system is conducted by the stable gear system,
it would be more stable when machine running at a high speed.
6. With automatic lubricating system, it will automatic lubricating to every moving parts when machine runs.
7. Every cam will be harden to ensure it can run for a long long time.
8. Machine is designed with double turning plate.
9. Equipped with automatic cup collecting stacking and counting system.
10. Bottom paper we have a special pre feeding system, so the bottom paper feeding is “0” waste.
11. Bottom is die cut and feed in to the finished cup body directly, so its more efficient and less
malfunctioning from bottom.
Application
The Machine Is Mainly Used to Produce Many Different Kinds Of Plastic Lids , Food Containers, Plastic Bowl, Plates , Toys Package, Food Trays , Hardward Trays, Medicine Trays and Etc.The Sheet Material Can Be HIPS, PVC, PET, PS.Custom Mould Is Welcomed.
